# Convolutional Neural Networks

Edouard Yvinec

.affiliations[
  ![Sorbonne](images/logo_sorbonne.png)
  ![Isir](images/logo_isir.png)
  ![Datakalab](images/logo_datakalab.png)
  ![Epita](images/Epita.png)
]

---
## Used everywhere for Vision

---
## Many other applications

### Speech recognition & speech synthesis

### Natural Language Processing

### Protein/DNA binding prediction

### Any problem with a spatial (or sequential) structure

---
## ConvNets for image classification

CNN = Convolutional Neural Networks = ConvNet

.footnote.small[
LeCun, Y., Bottou, L., Bengio, Y., and Haffner, P. (1998). Gradient-based learning applied to document recognition.
]

---
# Outline

### Convolutions

### CNNs for Image Classification

### CNN Architectures

---

# Convolutions

---
## Motivations

Standard Dense Layer for an image input:

```python
x = Input((640, 480, 3), dtype='float32')
# shape of x is: (None, 640, 480, 3)
x = Flatten()(x)
# shape of x is: (None, 640 x 480 x 3)
z = Dense(1000)(x)
```

How many parameters in the Dense layer?
--

$640 \times 480 \times 3 \times 1000 + 1000 = 922M !$

Spatial structure of the input is destroyed by `Flatten`

We never use Dense layers directly on large images. Most standard solution is **convolution** layers

---
### Fully Connected Network: MLP

```python
input_image = Input(shape=(28, 28, 1))
x = Flatten()(input_image)
x = Dense(256, activation='relu')(x)
x = Dense(10, activation='softmax')(x)
mlp = Model(inputs=input_image, outputs=x)
```
--
### Convolutional Network

```python
input_image = Input(shape=(28, 28, 1))
*x = Conv2D(32, 5, activation='relu')(input_image)
*x = MaxPool2D(2, strides=2)(x)
*x = Conv2D(64, 3, activation='relu')(x)
*x = MaxPool2D(2, strides=2)(x)
x = Flatten()(x)
x = Dense(256, activation='relu')(x)
x = Dense(10, activation='softmax')(x)
convnet = Model(inputs=input_image, outputs=x)
```
--
2D spatial structure of features preserved untill `Flatten`.

---
## Convolution in a neural network

- $x$ is a $3 \times 3$ chunk (dark area) of the image _(blue array)_
- Each output neuron is parametrized with the $3 \times 3$ weight matrix $\mathbf{w}$ _(small numbers)_

.footnote.small[
 These slides extensively use convolution visualisation by V.
Dumoulin available at https://github.com/vdumoulin/conv_arithmetic
]
---
## Convolution in a neural network

- $x$ is a $3 \times 3$ chunk (dark area) of the image _(blue array)_
- Each output neuron is parametrized with the $3 \times 3$ weight matrix $\mathbf{w}$ _(small numbers)_

The activation obtained by sliding the $3 \times 3$ window and computing:

$$
z(x) = relu(\mathbf{w}^T x + b)
$$

---
## Motivations

### Local connectivity
- A neuron depends only on a few local input neurons
- Translation invariance

### Comparison to Fully connected
- Parameter sharing: reduce overfitting
- Make use of spatial structure: **strong prior** for vision!

### Animal Vision Analogy
.small[
Hubel & Wiesel, RECEPTIVE FIELDS OF SINGLE NEURONES IN THE CAT'S STRIATE CORTEX (1959)
]

---
## Why Convolution

Discrete convolution (actually cross-correlation) between two functions
$f$ and $g$:

$$
(f \star g) (x) = \sum\_{a+b=x} f(a) . g(b) = \sum\_{a} f(a) . g(x + a)
$$

2D-convolutions (actually 2D cross-correlation):

$$
(f \star g) (x, y) = \sum_n \sum_m f(n, m) . g(x + n, y + m)
$$

$f$ is a convolution **kernel** or **filter** applied to the 2-d map
$g$ (our image)

---
## Example: convolution image

- Image: $im$ of dimensions $5 \times 5$
- Kernel: $k$ of dimensions $3 \times 3$

$ (k \star im) (x, y) = \sum\limits\_{n=0}^2 \sum\limits\_{m=0}^2 k(n, m) . im(x + n - 1, y + m - 1) $

???
This formula actually implements a cross-correlation instead of a true
convolution:

https://en.wikipedia.org/wiki/Cross-correlation

The formula for an actual convolution would be:

$ (k \star im) (x, y) = \sum\limits\_{n=0}^2 \sum\limits\_{m=0}^2 k(n, m) . im(x - n + 1, y - m + 1) $

Then the indexing of the kernel components would be done in the opposite
direction of the image indexing in that case.

In practice, convnets can use either cross-correlations or true
convolutions, this does not have any impact on the final function
computed by the network as the kernel parameters are initialized
randomly and are trained to minimize the loss on the training set in
both cases.

---
## Channels

Colored image = tensor of shape `(height, width, channels)`

Convolutions are usually computed for each channel and summed:

$$
(k \star im^{color}) = \sum\limits\_{c=0}^2 k^c \star im^c
$$

---
## Multiple convolutions

---
## Multiple convolutions

---
## Multiple convolutions

---
## Multiple convolutions

---
## Multiple convolutions

--
- Kernel size aka receptive field (usually 1, 3, 5, 7, 11)
- Output dimension: `length - kernel_size + 1`

---
## Strides

- Strides: increment step size for the convolution operator
- Reduces the size of the output map

.center.small[
Example with kernel size $3 \times 3$ and a stride of $2$ (image in blue)
]
---
## Padding

- Padding: artificially fill borders of image
- Useful to keep spatial dimension constant across filters
- Useful with strides and large receptive fields
- Usually: fill with 0s

---
## Dealing with shapes

**Kernel** or **Filter** shape $(F, F, C^i, C^o)$

Number of parameters: $(F \times F \times C^i + 1) \times C^o$

**Activations** or **Feature maps** shape:
- Input $(W^i, H^i, C^i)$
- Output $(W^o, H^o, C^o)$

$W^o = (W^i - F + 2P) / S + 1$

???

The **filters** holds the **trainable parameters** of the model (excluding the biases).

The **feature maps** are the outputs (or **activations**) of convolution
layers when **applied to a specific batch of images**.

---
## Pooling

- Spatial dimension reduction
- Local invariance
- No parameters: max or average of 2x2 units

.footnote.small[
Schematic from Stanford http://cs231n.github.io/convolutional-networks
]
---
## Pooling

- Spatial dimension reduction
- Local invariance
- No parameters: max or average of 2x2 units

---

class:middle, center

# Architectures

---
## Classic ConvNet Architecture

### Input

### Conv blocks

- Convolution + activation (relu)
- Convolution + activation (relu)
- ...
- Maxpooling 2x2

### Output

- Fully connected layers
- Softmax

---
# AlexNet

.footnote.small[
Simplified version of Krizhevsky, Alex, Sutskever, and Hinton. "Imagenet classification with deep convolutional neural networks." NIPS 2012
]

Input: 227x227x3 image
First conv layer: kernel 11x11x3x96 stride 4

- Kernel shape: `(11,11,3,96)`
- Output shape: `(55,55,96)`
- Number of parameters: `34,944`
- Equivalent MLP parameters: `43.7 x 1e9`

---
## AlexNet

```md
INPUT:     [227x227x3]
CONV1:     [55x55x96]   96 11x11 filters at stride 4, pad 0
MAX POOL1: [27x27x96]      3x3   filters at stride 2
CONV2:     [27x27x256] 256 5x5   filters at stride 1, pad 2
MAX POOL2: [13x13x256]     3x3   filters at stride 2
CONV3:     [13x13x384] 384 3x3   filters at stride 1, pad 1
CONV4:     [13x13x384] 384 3x3   filters at stride 1, pad 1
CONV5:     [13x13x256] 256 3x3   filters at stride 1, pad 1
MAX POOL3: [6x6x256]       3x3   filters at stride 2
FC6:       [4096]      4096 neurons
FC7:       [4096]      4096 neurons
FC8:       [1000]      1000 neurons (softmax logits)
```
---
## Hierarchical representation

---
## VGG-16

.footnote.small[
Simonyan, Karen, and Zisserman. "Very deep convolutional networks for large-scale image recognition." (2014)
]
---
## VGG in Keras

```python
    model.add(Convolution2D(64, 3, 3, activation='relu',input_shape=(3,224,224)))
    model.add(Convolution2D(64, 3, 3, activation='relu'))
    model.add(MaxPooling2D((2,2), strides=(2,2)))

model.add(Convolution2D(128, 3, 3, activation='relu'))
    model.add(Convolution2D(128, 3, 3, activation='relu'))
    model.add(MaxPooling2D((2,2), strides=(2,2)))

model.add(Convolution2D(256, 3, 3, activation='relu'))
    model.add(Convolution2D(256, 3, 3, activation='relu'))
    model.add(Convolution2D(256, 3, 3, activation='relu'))
    model.add(MaxPooling2D((2,2), strides=(2,2)))

model.add(Convolution2D(512, 3, 3, activation='relu'))
    model.add(Convolution2D(512, 3, 3, activation='relu'))
    model.add(Convolution2D(512, 3, 3, activation='relu'))
    model.add(MaxPooling2D((2,2), strides=(2,2)))

model.add(Flatten())
    model.add(Dense(4096, activation='relu'))
    model.add(Dropout(0.5))
    model.add(Dense(4096, activation='relu'))
    model.add(Dropout(0.5))
    model.add(Dense(1000, activation='softmax'))
```

---
## Memory and Parameters

```md
           Activation maps          Parameters
INPUT:     [224x224x3]   = 150K     0
CONV3-64:  [224x224x64]  = 3.2M     (3x3x3)x64    =       1,728
CONV3-64:  [224x224x64]  = 3.2M     (3x3x64)x64   =      36,864
POOL2:     [112x112x64]  = 800K     0
CONV3-128: [112x112x128] = 1.6M     (3x3x64)x128  =      73,728
CONV3-128: [112x112x128] = 1.6M     (3x3x128)x128 =     147,456
POOL2:     [56x56x128]   = 400K     0
CONV3-256: [56x56x256]   = 800K     (3x3x128)x256 =     294,912
CONV3-256: [56x56x256]   = 800K     (3x3x256)x256 =     589,824
CONV3-256: [56x56x256]   = 800K     (3x3x256)x256 =     589,824
POOL2:     [28x28x256]   = 200K     0
CONV3-512: [28x28x512]   = 400K     (3x3x256)x512 =   1,179,648
CONV3-512: [28x28x512]   = 400K     (3x3x512)x512 =   2,359,296
CONV3-512: [28x28x512]   = 400K     (3x3x512)x512 =   2,359,296
POOL2:     [14x14x512]   = 100K     0
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
POOL2:     [7x7x512]     =  25K     0
FC:        [1x1x4096]    = 4096     7x7x512x4096  = 102,760,448
FC:        [1x1x4096]    = 4096     4096x4096     =  16,777,216
FC:        [1x1x1000]    = 1000     4096x1000     =   4,096,000

TOTAL activations: 24M x 4 bytes ~=  93MB / image (x2 for backward)
TOTAL parameters: 138M x 4 bytes ~= 552MB (x2 for plain SGD, x4 for Adam)
```
---
## Memory and Parameters

```md
           Activation maps          Parameters
INPUT:     [224x224x3]   = 150K     0
*CONV3-64:  [224x224x64]  = 3.2M     (3x3x3)x64    =       1,728
*CONV3-64:  [224x224x64]  = 3.2M     (3x3x64)x64   =      36,864
POOL2:     [112x112x64]  = 800K     0
CONV3-128: [112x112x128] = 1.6M     (3x3x64)x128  =      73,728
CONV3-128: [112x112x128] = 1.6M     (3x3x128)x128 =     147,456
POOL2:     [56x56x128]   = 400K     0
CONV3-256: [56x56x256]   = 800K     (3x3x128)x256 =     294,912
CONV3-256: [56x56x256]   = 800K     (3x3x256)x256 =     589,824
CONV3-256: [56x56x256]   = 800K     (3x3x256)x256 =     589,824
POOL2:     [28x28x256]   = 200K     0
CONV3-512: [28x28x512]   = 400K     (3x3x256)x512 =   1,179,648
CONV3-512: [28x28x512]   = 400K     (3x3x512)x512 =   2,359,296
CONV3-512: [28x28x512]   = 400K     (3x3x512)x512 =   2,359,296
POOL2:     [14x14x512]   = 100K     0
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
CONV3-512: [14x14x512]   = 100K     (3x3x512)x512 =   2,359,296
POOL2:     [7x7x512]     =  25K     0
*FC:        [1x1x4096]    = 4096     7x7x512x4096  = 102,760,448
FC:        [1x1x4096]    = 4096     4096x4096     =  16,777,216
FC:        [1x1x1000]    = 1000     4096x1000     =   4,096,000

TOTAL activations: 24M x 4 bytes ~=  93MB / image (x2 for backward)
TOTAL parameters: 138M x 4 bytes ~= 552MB (x2 for plain SGD, x4 for Adam)
```
---
.left-column[
## ResNet
]

.footnote.small[
.left-column[
He, Kaiming, et al. "Deep residual learning for image recognition." CVPR. 2016.
]
]

Even deeper models:

34, 50, 101, 152 layers

---
.left-column[
## ResNet
]

.footnote.small[
.left-column[
He, Kaiming, et al. "Deep residual learning for image recognition." CVPR. 2016.
]
]

A block learns the residual w.r.t. identity

- Good optimization properties

---
.left-column[
## ResNet
]

.footnote.small[
.left-column[
He, Kaiming, et al. "Deep residual learning for image recognition." CVPR. 2016.
]
]

ResNet50 Compared to VGG:

#### Superior accuracy in all vision tasks **5.25%** top-5 error vs 7.1%

#### Less parameters **25M** vs 138M

#### Computational complexity **3.8B Flops** vs 15.3B Flops

#### Fully Convolutional until the last layer

---
## Deeper is better

.footnote.small[
from Kaiming He slides "Deep residual learning for image recognition." ICML. 2016.
]
---
## State of the art

- Finding right architectures: Active area or research

Modular building blocks engineering

.footnote.small[
from  He slides "Deep residual learning for image recognition." ICML. 2016.
]

see also DenseNets, Wide ResNets, Fractal ResNets, ResNeXts,
  Pyramidal ResNets

---
## State of the art

#### Top 1-accuracy, performance and size on ImageNet

See also: https://paperswithcode.com/sota/image-classification-on-imagenet

.footnote.small[
Canziani, Paszke, and Culurciello. "An Analysis of Deep Neural Network Models for Practical Applications." (May 2016).
]

---
## More ImageNet SOTA

.footnote.small[
- Mingxing Tan, Quoc V. Le, [EfficientNet: Rethinking Model Scaling for Convolutional Neural Networks
](https://arxiv.org/abs/1905.11946), ICML 2019.
- Irwan Bello, [LambdaNetworks: Modeling long-range Interactions without Attention](https://openreview.net/forum?id=xTJEN-ggl1b), ICLR 2021
- Dosovitskiy A. et al, [An Image is worth 16X16 Words: Transformers for Image Recognition at Scale](https://arxiv.org/pdf/2010.11929.pdf), ICLR 2021
]

---
## State of the art

.footnote.small[
Meta Pseudo Labels, Hieu Pham et al. (Jan 2021)
]

---
class: middle, center

# Pre-trained models

---
## Pre-trained models

Training a model on ImageNet from scratch takes **days or weeks**.

Many models trained on ImageNet and their weights are publicly
available!

### Transfer learning

- Use pre-trained weights, remove last layers to compute representations of images
- Train a classification model from these features on a new classification task
- The network is used as a generic feature extractor
- Better than handcrafted feature extraction on natural images

---
## Pre-trained models

Training a model on ImageNet from scratch takes **days or weeks**.

Many models trained on ImageNet and their weights are publicly
available!

### Fine-tuning

#### Retraining the (some) parameters of the network (given enough data)

- Truncate the last layer(s) of the pre-trained network
- Freeze the remaining layers weights
- Add a (linear) classifier on top and train it for a few epochs

--
- Then fine-tune the whole network or the few deepest layers
- Use a smaller learning rate when fine tuning

---
## Data Augmentation

--
.center[
<img src="images/augmented-cat.png" style="width: 550px" />
]

See also: [RandAugment](https://arxiv.org/abs/1909.13719) and
[Unsupervised Data Augmentation for Consistency Training](
  https://arxiv.org/abs/1904.12848).

???
- Use prior knowledge on label-invariant transformation
- A rotated picture of a cat is still a picture of a cat.
- Effective way to reduce overfitting on small labeled sets.
- Can be very efficient in a Semi-Supervised setting when combined
  with a consistency loss.

---
## Data Augmentation

With Keras:

```python
from keras.preprocessing.image import ImageDataGenerator

image_gen = ImageDataGenerator(
    rescale=1. / 255,
    rotation_range=40,
    width_shift_range=0.2,
    height_shift_range=0.2,
    shear_range=0.2,
    zoom_range=0.2,
    horizontal_flip=True,
    channel_shift_range=9,
    fill_mode='nearest'
)

train_flow = image_gen.flow_from_directory(train_folder)
model.fit_generator(train_flow, train_flow.n)
```

---

# Lab 4: Back here in 15min!
